·R&D in Laboratory ·System Monitoring ·OADM ·MAN (Metropolitan Area Network)
Fiberer-FSW-D2X2 Optical Switch, which is famous for its high performance, low insertion loss and compact dimension: (L)28.5X(W)12.6X(H)8.7mm （SM）; (L)27.0X(W)12.6X(H)8.2mm （MM）. It is an ideal component for OADM，OXC，system monitoring and protection. With compact package, it can be easy to integrate into a high density optical communication system.
Dual fiber Optic Switch, Dual fibre optic switch- SM Specifications
Parameters
Unit
Fiberer-FSW-D2X2-S
Wavelength Range
nm
1260 ~ 1650
Test Wavelength
nm
1310 / 1550
Insertion Loss 1, 2
dB
Typ: 1.0 Max: 1.5
Return Loss 1, 2
dB
≥ 50
Crosstalk 1
dB
≥ 55
PDL
dB
≤0.05
WDL
dB
≤0.25
Repeatability
dB
≤±0.02
Operating Voltage
V
3.0 or 5.0
Durability
Cycles
≥ 10 Million
Switching Time
ms
≤8
Optical Power
mW
≤500
Operating Temperature
℃
-5 ~ +70
Storage Temperature
℃
-40 ~ +85
Relative Humidity
%
5 ~ 95
Weight
g
16
Dimension
mm
(L)28.5X(W)12.6X(H)8.7 ±0.2
Note: 1 Within operating temperature and SOP. 2 Excluding Connectors.
To protect each of product, Fiberer will use firm and secure Package, and common use Fiberer Label if customer not remark.
It is available to use custmized labeling and packaging for customer request.
Shipment
All shipment will be succssful to arrive customer's address. Fiberer try our best to let the shipment fast for customers, and the common express is by air of Fedex, DHL, UPS, EMS and TNT.
If the customer pay Fiberer the shipment charge, it will use Fiberer express account for the shipment, otherwise it need to use the customer's express account.
Customized & OEM
Fiberer always do Customized for customer's request successfully, It is available for Customized & OEM.
Quality Assurance:
assure 100% best quality.
(Fiberer assure 100% best quality.the term will be signed on order and
invoice,match the safety of international business
