Mini Dual Fiber Optic Switch,Mini Dual Optical Switch - Features：
·Low Insertion Loss
·Wide Wavelength Range
·Low Crosstalk
·High Stability
·High Reliability
·Epoxy-free on Optical Path
·Latching and Non-latching
Mini Dual Fiber Optic Switch,Mini Dual Optical Switch - Applications：
·R&D in Laboratory
·System Monitoring
·OADM
·MAN (Metropolitan Area Network)
Mini Dual Fiber Optic Switch,Mini Dual Optical Switch - Specification
|
Parameters |
Unit |
MD1×2 or MD2×2 or MD2×2B |
MD1×2 or MD2×2B |
|
Wavelength Range |
nm |
850±40 / 1300±40 |
1260 ~ 1650 |
|
Test Wavelength |
nm |
850 / 1310 |
1310 / 1550 |
|
Insertion Loss 1, 2, |
dB |
Typ: 0.8 Max: 1.2 |
|
Return Loss 1, 2, |
dB |
MM ≥ 30 SM ≥ 50 |
|
Crosstalk 1, |
dB |
MM ≥ 35 SM ≥ 55 |
|
PDL |
dB |
≤0.05 |
|
WDL |
dB |
≤0.3 |
|
Repeatability |
dB |
≤±0.02 |
|
Operating Voltage |
V |
5.0 |
|
Voltage Pulse Width
(Latching)
|
ms |
≥ 20 |
|
Durability |
Cycles |
≥ 10 Million |
|
Switching Time |
ms |
≤8 |
|
Optical Power |
mW |
≤500 |
|
Operating
Temperature
|
℃ |
-5 ~ +70 |
|
Storage
Temperature
|
℃ |
-40 ~ +85 |
|
Relative Humidity |
% |
5 ~ 95 |
|
Dimension |
mm |
(L)21.0×(W)9.0×(H)12.0 ± 0.2 |
|
Note: 1 Within operating temperature and SOP.
2 Excluding Connectors. |
Mini Dual Fiber Optic Switch,Mini Dual Optical Switch - Pin Configurations
|
Type |
State |
Optical Route |
Electric Drive |
Status Sensor |
|
MD1×2 |
|
|
Pin 1 |
Pin 8 |
Pin 2-3 |
Pin 3-4 |
Pin 5-6 |
Pin 6-7 |
|
|
A |
P1-P2 |
5V Pulse |
GND |
Open |
Close |
Close |
Open |
|
P1’-P2’ |
|
Latching |
|
|
B |
P1-P3 |
GND |
5V Pulse |
Close |
Open |
Open |
Close |
|
P1’-P3’ |
|
Non
-latching |
A |
P1-P2 |
5V Pulse |
GND |
Open |
Close |
Close |
Open |
|
P1’-P2’ |
|
B |
P1-P3 |
-- |
-- |
Close |
Open |
Open |
Close |
|
P1’-P3’ |
|
Type |
State |
Optical Route |
Electric Drive |
Status Sensor |
|
MD2×2 |
|
|
Pin 1 |
Pin 8 |
Pin 2-3 |
Pin 3-4 |
Pin 5-6 |
Pin 6-7 |
|
|
A |
P1-P4，P3-P2 |
5V Pulse |
GND |
Open |
Close |
Close |
Open |
|
P1’-P4’，P3’-P2’ |
|
Latching |
|
|
B |
P1-P2，P3-P4 |
GND |
5V Pulse |
Close |
Open |
Open |
Close |
|
P1’-P2’，P3’-P4’ |
|
Non
-latching |
A |
P1-P4，P3-P2 |
5V Pulse |
GND |
Open |
Close |
Close |
Open |
|
P1’-P4’，P3’-P2’ |
|
B |
P1-P2，P3-P4 |
-- |
-- |
Close |
Open |
Open |
Close |
|
P1’-P2’，P3’-P4’ |
|
Type |
State |
Optical Route |
Electric Drive |
Status Sensor |
|
MD2×2B |
|
|
Pin 1 |
Pin 8 |
Pin 2-3 |
Pin 3-4 |
Pin 5-6 |
Pin 6-7 |
|
|
A |
P1-P4，P3-P2 |
5V Pulse |
GND |
Open |
Close |
Close |
Open |
|
P1’-P4’，P3’-P2’ |
|
Latching |
|
|
B |
P1-P3 |
GND |
5V Pulse |
Close |
Open |
Open |
Close |
|
P1’-P3’ |
|
Non
-latching |
A |
P1-P4，P3-P2 |
5V Pulse |
GND |
Open |
Close |
Close |
Open |
|
P1’-P4’，P3’-P2’ |
|
B |
P1-P3 |
-- |
-- |
Close |
Open |
Open |
Close |
|
P1’-P3’ |
Mini Dual Fiber Optic Switch,Mini Dual Optical Switch- Optical Route
MD1×2
MD2×2
MD2×2B
Mini Dual Fiber Optic Switch,Mini Dual Optical Switch - Electrical Specification
|
Specifications |
Voltage |
Current |
Resistance |
|
5V latching |
4.5~5.5 V |
22.2（±10%） mA |
202.5（±10%） Ω |
|
5V non-latching |
4.5~5.5 V |
31（±10%） mA |
145（±10%） Ω |
|
3V latching |
2.7~3.3 V |
33.3（±10%） mA |
90（±10%） Ω |
|
3V non-latching |
2.7~3.3 V |
46.7（±10%） mA |
64.2（±10%） Ω |
Mini Dual Fiber Optic Switch, Mini Dual Optical Switch - Ordering Information: FIBERER-FSW-A-B-C-D-E-F-G-H
|
A |
B |
C |
D |
E |
F |
G |
H |
|
Optical
Switch Type |
Fiber
Type |
Operating
Voltage |
Switch Type
|
Test Wavelength
|
Tube
Type |
Fiber Length
(Include connector) |
Connector |
|
MD1×2
MD2×2
MD2×2B |
SM:SM,
9/125
M5:MM,
50/125
M6:MM,
62.5/125
X: Others |
5: 5V
3: 3V |
L: Latching
N:
Non-latc hing |
850: 850 nm
1310: 1310 nm
1550:1550n m
8513:
850&1310 nm(MM)
1315:
1310&1550 nm（SM）
X:Others |
25:250 um
90:900 um
X: Others |
05: 0.5m±5cm
10: 1.0m±5cm
15: 1.5m±5cm
X: Others |
OO:None
FP: FC/PC
FA: FC/APC
SP: SC/PC
SA: SC/APC
STP: ST/PC
LP: LC/PC
LA: LC/APC
DLP: Duplex
LC/PC
MTP：MTP
X: Others |
